ISO-K

Cross, stainless steel

Cross-Stainless-Steel-ISO-K
Drop-in Options

Revolutionize your vacuum gauge experience with us!

Product configurator

Gemini™ MxG5xx

Type
Sensor version
Ionization chamber
Emmision current
Flange connection to vacuum chamber
Switching function
Electrical connection
Digital interface
Analog output signal
Your configuration
inficon-gauge
Gemini™ MxG5xx
Flange
DN 16 ISO-KF
Switching functions
None
Electrical Connection
FCC, 8-pin
Digital Interface
None
Measurement range
1.2 - 8.68 V
Request
Personal information
Product
inficon-gauge
Gemini™ MxG5xx
Gemini™ MAG500
Your configuration has been successfully sent!

INFICON ISO-K quality fittings are manufactured according to ISO 1609, DIN 28404 and Pneurop 6606. Our quality large diameter fittings are the standard vacuum components for all vacuum and high vacuum lines. The high quality INFICON fittings are designed and tested for leak rates less than 1 x 10-9 mbar l/s.

Advantages

  • Competitively priced
  • World wide logistics
  • Design and measures follow strictly international respected standards
  • Surface finish, welds, material specifications and cleanliness meet or exceed high vacuum specifications
  • 2011/65/EU RoHS compliant

Specifications

 Dimension ADimension B
DN63 ISO-K88 mm66 mm
DN100 ISO-K108 mm100 mm
DN160 ISO-K138 mm150 mm
DN200 ISO-K178 mm213 mm
DN250 ISO-K208 mm250 mm

Material: stainless steel 304



Download full specifications

Part Number

Part NumberDescription
212-121Cross piece, inox, DN63 ISO-K
212-122Cross piece, inox, DN100 ISO-K
212-123Cross piece, inox, DN160 ISO-K
212-124Cross piece, inox, DN200 ISO-K
212-125Cross piece, inox, DN250 ISO-K
