Hydrogen and Helium Leak Detector

XL3000flex

HIGH FLOW Technology for Highest Measurement Certainty and Fastest Throughput

XL3000flex

Product configurator

Gemini™ MxG5xx

Type
Sensor version
Ionization chamber
Emmision current
Flange connection to vacuum chamber
Switching function
Electrical connection
Digital interface
Analog output signal
Your configuration
inficon-gauge
Gemini™ MxG5xx
Flange
DN 16 ISO-KF
Switching functions
None
Electrical Connection
FCC, 8-pin
Digital Interface
None
Measurement range
1.2 - 8.68 V
Request
Personal information
Product
inficon-gauge
Gemini™ MxG5xx
Gemini™ MAG500
Your configuration has been successfully sent!

XL3000flex sniffer leak detector is the first device to detect leaks with forming gas (95% nitrogen and 5% hydrogen) as accurately as with helium, with a smallest detectable leak rate of 2 ∙ 10-7 mbar∙l/s for both test gases.

The XL3000flex provides the best flexibility to choose the test gas which is easiest to obtain according to lower cost. In addition, the XL3000flex uses the INFICON High Flow Technology: the device operates with a gas flow of 3000 sccm - the highest gas flow available on the market today. This allows the sniffer tip to be moved over the test piece at some distance and at a higher speed, so even the most inexperienced operators can achieve reliable results with the XL3000flex.

An additional advantage of the high gas flow is that it is the only way to enable reliable robotic sniffer leak testing.

Advantages

  • INFICON High Flow Technology
  • enables unmatched measurement certainty - stop missing leaks!
  • finds leaks even in hard to access areas
  • helps unexperienced operators to reliably locate leaks
  • creates highest througput testing
  • is ideally suited for robotic testing  - allows for maximum transversal speed even at some distance to the part
  • Minimize your operating cost - select the tracer gas of your choice!
  • Foolproof handling for manual leak detection process
  • redundant leak alarms - leaks cannot be overlooked!
  • ergonomically designed sniffer probe with Display - user can concentrate on the sniffing process and monitor the leakage rate simultaneously
  • Easy integration options for robot applications with Fieldbus Interface

Typical Applications

Manual or automated leak testing for Sub-assembly and midproduction of:

  • Refrigerators
  • Freezers
  • Air conditioners
  • Automotive air conditioners
  • Heating and Ventilation
  • RAC components
  • Automotive components and similar products.

Specifications

Minimum detectable leak ratembar•L/s2E-7 (low flow)
2E-6 (high flow)
Gas flowsccm300 (low flow)
3000 (high flow)
Measurable gases Helium, H2
Response time <1 s
Part Number
Accessories
Consumables
520-200Sniffer Leak detector XL3000flex
521-035Adapter customer sniffer line P3000XL
520-201Sniffer Leak Detector XL3000flexRC
12339External Sniffer Test Leak H2/HeCal leak
520-250CalMate
521-015Adapter customer sniffer line P3000XL
521-016Oil / Water Protection Tip for SL3000XL
521-017Filter for Oil/Water Protection Tip
521-018Sniffer tip ST312XL, 120 mm, rigid
521-019Sniffer tip FT312XL, 120 mm, flexible
521-020Sniffer tip ST385XL, 385 mm, rigid
521-021Sniffer tip FT385XL, 385 mm, flexible
521-022Sniffer tip FT250XL, 250 mm, flexible
521-035Adapter customer sniffer line P3000XL
560-310I/O 1000 module
560-315BM1000 Profibus module
560-316BM1000 PROFINET IO module
560-317BM1000 DeviceNet module
560-318BM1000 Ethernet/IP module
521-011SL3000XL-3, 3m length
521-012SL3000XL-5, 5m length
521-013SL3000XL-10, 10m length
521-014SL3000XL-15, 15m length
12237Test leak for Helium S-TL4
12322CAl leak, Forming Gas 5%H2
12339External Sniffer Test Leak H2/HeCal leak
