Vacuum Gauge Controller
TPG36x
Advanced controller for process measurement and data recording
Drop-in Options
Revolutionize your vacuum gauge experience with us!
Product configurator
Gemini™ MxG5xx
Type
Sensor version
Ionization chamber
Emmision current
Flange connection to vacuum chamber
Switching function
Electrical connection
Digital interface
Analog output signal
Request
Your configuration has been successfully sent!
As multifunctional controllers for process measurement, control and data logging, the TPG361 and TPG362 active pressure gauge controllers are designed to work seamlessly with a wide range of active compact pressure gauges. They efficiently manage and log data across a comprehensive pressure range from 10-10 to 1500 mbar (10-10 to 1125 Torr).
Advantages
- Easy-to-use dot matrix menu interface for adjusting parameters, sensors or general settings
- Clearly visible and bright display for remote reading of device data
- Bar graph for visualizing setpoints or displaying pressure over time
- Data log and parameter backup function with USB stick (front side)
- Firmware updates are available online or via USB stick
- Two free definable setpoints per channel with adjustable hysteresis
- High-precision data evaluation with a 16-bit A/D converter
- Automatic identification of the INFICON active compact gauges
- Ethernet- und RS485- und USB interface
Specifications
TPG361
TPG362
| Type | TPG361 |
| Measurement channels | 1 |
| Display | LCD, LED backlight |
| Rate 1/s | 10 |
| Connectable gauges with display range | |
| CMR (A/D) Torr | 1×10-3×F.S. … 1×F.S. |
| PCR mbar / Torr | 5×10-5 … 1500 / 3.75×10-5 … 1125 |
| TPR mbar / Torr | 1×10-4 … 1000 / 7.5×10-5 … 750 |
| PKR mbar / Torr | 1×10-9 … 1000 / 7.5×10-10 … 750 |
| IKR mbar / Torr | 1×10-9 … 1×10-2 / 7.5×10-10 … 7.5×10-3 |
| APR mbar / Torr | 0.1 … 55000 / 7.5×10-2 … 4.125×104 |
| PBR mbar / Torr | 5×10-10 … 1000 / 3.75×10-10 … 750 |
| IMR mbar / Torr | 2×10-6 … 1000 / 1.5×10-6 … 750 |
| Measurement unit (selectable) | mbar, Torr, Pa, hPa, Micron, V |
| Setpoints | |
| Setpoint relays | 2 |
| Channel assignment | 1 |
| Adjustment range | sensor dependent |
| Hysteresis | adjustable |
| Relay contact | floating changeover contact |
| Contact rating V (ac) / A | 30 / 1 |
| Contact rating V (dc) / A | 60 / 0.5 |
| Connector | D-sub, 15-pin, female |
| Analog output | |
| Range V | 0 ... 10.3, sensor analog output signal |
| Analog output | 1 |
| Connector | Amphenol C91B, 7‑pin, female |
| Interface (digital) | USB slave, master, Ethernet and RS485 |
| Connector | USB Type A (stick), USB Type B, FCC68/RJ45, Binder M12 |
| Power | |
| Supply V (ac) | 100 ... 240 |
| Frequency Hz | 50 ... 60 |
| Consumption W | ≤45 |
| Operation temperature (ambiance) °C | +5 ... +50 |
| Type | TPG362 |
| Measurement channels | 2 |
| Display | LCD, LED backlight |
| Rate 1/s | 10 |
| Connectable gauges with display range | |
| CMR (A/D) Torr | 1×10-3×F.S. … 1×F.S. |
| PCR mbar / Torr | 5×10-4 … 1500 / 3.75×10-4 … 1125 |
| TPR mbar / Torr | 5×10-4 … 1000 / 3.75×10-4 … 750 |
| PKR mbar / Torr | 1×10-9 … 1000 / 7.5×10-10 … 750 |
| IKR mbar / Torr | 1×10-9 … 1×10-2 / 7.5×10-10 … 7.5×10-3 |
| APR mbar / Torr | 0.1 … 55000 / 7.5×10-2 … 4.125×104 |
| PBR mbar / Torr | 5×10-10 … 1000 / 3.75×10-10 … 750 |
| IMR mbar / Torr | 2×10-6 … 1000 / 1.5×10-6 … 750 |
| Measurement unit (selectable) | mbar, Torr, Pa, hPa, Micron, V |
| Setpoints | |
| Setpoint relays | 4 |
| Channel assignment | 1 or 2 |
| Adjustment range | sensor dependent |
| Hysteresis | adjustable |
| Relay contact | floating changeover contact |
| Contact rating V (ac) / A | 30 / 1 |
| Contact rating V (dc) / A | 60 / 0.5 |
| Connector | D-sub, 15-pin, female |
| Analog output | |
| Range V | 0 ... 10.3, sensor analog output signal |
| Analog output | 2 |
| Connector | Amphenol C91B, 7‑pin, female |
| Interface (digital) | USB slave, master, Ethernet and RS485 |
| Connector | USB Type A (stick), USB Type B, FCC68/RJ45, Binder M12 |
| Power | |
| Supply V (ac) | 100 ... 240 |
| Frequency Hz | 50 ... 60 |
| Consumption W | ≤65 |
| Operation temperature (ambiance) °C | +5 ... +50 |
Drop-in Replacement
Part number
Part number
| INFICON | Pfeiffer Vacuum | |
| TPG361 | IGD28040 | PTG28040 |
| TPG362 | IGD28290 | PTG28290 |
