ISO-KF
Reducer, stainless steel 304

Product configurator
Gemini™ MxG5xx
Type
Sensor version
Ionization chamber
Emmision current
Flange connection to vacuum chamber
Switching function
Electrical connection
Digital interface
Analog output signal
Request
Your configuration has been successfully sent!
INFICON ISO-KF fittings are manufactured according to ISO 2861/1, DIN 28403 and Pneurop 6606. Our quality fittings are the standard components for all vacuum and high vacuum applications. The high quality INFICON components are designed and tested for leak rates less than 1 x 10-9 mbar l/s.
Advantages
- Competitively priced
- World wide logistics
- Design and measures follow strictly international respected standards
- Surface finish, welds, material specifications and cleanliness meet or exceed high vacuum specifications
- 2011/65/EU RoHS compliant
Specifications
Dimension A | Dimension B | |
DN25/16 ISO-KF | 40 mm | 16 mm |
DN40/16 ISO-KF | 40 mm | 16 mm |
DN40/25 ISO-KF | 40 mm | 26 mm |
DN50/16 ISO-KF | 40 mm | 16 mm |
DN50/25 ISO-KF | 40 mm | 26 mm |
DN50/40 ISO-KF | 40 mm | 40 mm |
Part Number
Part Number | Description | |
DN25/16 ISO-KF | 211-281 | Reducing intermediate piece, SS, DN25/16 ISO-KF |
DN40/16 ISO-KF | 211-282 | Reducing intermediate piece, SS, DN40/16 ISO-KF |
DN40/25 ISO-KF | 211-283 | Reducing intermediate piece, SS, DN40/25 ISO-KF |
DN50/16 ISO-KF | 211-323 | Reducing intermediate piece, SS, DN50/16 ISO-KF |
DN50/25 ISO-KF | 211-324 | Reducing intermediate piece, SS, DN50/25 ISO-KF |
DN50/40 ISO-KF | 211-284 | Reducing intermediate piece, SS, DN50/40 ISO-KF |
