1. Reducing Cross, stainless steel 304
ISO-KF

Reducing Cross, stainless steel 304

Reducing-Cross-Aluminum
Drop-in Options

Revolutionize your vacuum gauge experience with us!

Discover more

Product configurator

Gemini™ MxG5xx

Type
Sensor version
Ionization chamber
Emmision current
Flange connection to vacuum chamber
Switching function
Electrical connection
Digital interface
Analog output signal
Your configuration
inficon-gauge
Gemini™ MxG5xx
Flange
DN 16 ISO-KF
Switching functions
None
Electrical Connection
FCC, 8-pin
Digital Interface
None
Measurement range
1.2 - 8.68 V
Request
Personal information

You can unsubscribe from these communications at any time. For more information please review our Privacy Policy.

Product
inficon-gauge
Gemini™ MxG5xx
Gemini™ MAG500
Your configuration has been successfully sent!
Back

INFICON ISO-KF fittings are manufactured according to ISO 2861/1, DIN 28403 and Pneurop 6606. Our quality fittings are the standard components for all vacuum and high vacuum applications. The high quality INFICON components are designed and tested for leak rates less than 1 x 10-9 mbar l/s.

Advantages

  • Competitively priced
  • World wide logistics
  • Design and measures follow strictly international respected standards
  • Surface finish, welds, material specifications and cleanliness meet or exceed high vacuum specifications
  • 2011/65/EU RoHS compliant

Specifications

 DN25/16 ISO-KFDN40/16 ISO-KFDN50/16 ISO-KF
Dimension A35 mm40 mm50 mm
Dimension B70 mm80 mm100 mm
Dimension C35 mm45 mm50 mm
Dimension D70 mm90 mm100 mm
Dimension E25 mm40.5 mm53 mm

Dimension F



17 mm16 mm16 mm

Dimension Drawing

Dimension Drawing
Download full specifications

Part Number

 Part NumberDescription
DN25/16 ISO-KF211-301Reducing cross piece, inox, DN25/16 ISO-KF
DN40/16 ISO-KF211-302Reducing cross piece, inox, DN40/16 ISO-KF
DN50/16 ISO-KF211-303Reducing cross piece, inox, DN50/16 ISO-KF
