Refrigerant Leak Detector

Compass®

A new direction in features, function and value

Compass

Product configurator

Gemini™ MxG5xx

Type
Sensor version
Ionization chamber
Emmision current
Flange connection to vacuum chamber
Switching function
Electrical connection
Digital interface
Analog output signal
Your configuration
inficon-gauge
Gemini™ MxG5xx
Flange
DN 16 ISO-KF
Switching functions
None
Electrical Connection
FCC, 8-pin
Digital Interface
None
Measurement range
1.2 - 8.68 V
Request
Personal information
Product
inficon-gauge
Gemini™ MxG5xx
Gemini™ MAG500
Your configuration has been successfully sent!

Integral to Compass is the INFICON heated diode sensor technology, delivering outstanding sensitivity to all refrigerants yet resisting jobsite contaminants such as dust, dirt and oil.

For maximum versatility and ease of use, Compass has features such as rechargeable batteries, the ability to operate on AC power, adjustable high/low sensitivity and a series of LED leak indicators. The ergonomic design with rubberized grip fits your hand perfectly for comfortable, secure operation.

Features

  • Runs on NiMH batteries or AC adapter
  • Headphone jack
  • Made in USA
  • 2-year over-the-counter replacement warranty

Advantages

  • Heated diode sensor provides excellent sensitivity
  • Detects R22, R134a, R404a, R410a, R448a, R507 (AZ-50), R32, HFO1234yf, and all other CFCs, HCFCs, HFCs, and HFOs
  • Automatic background adjustment (“zeroing”)
  • Intuitive, easy one button operation
  • Power indicator shows when battery is low

Specifications

Base unit includesSensor, NiMH battery, spare filters, wall charger, 12 V car charger, hard plastic carrying case
Minimum sensitivity0.15 oz/year (4 g/a)
Power sourceNiMH battery, AC adapter
CertificationsCE marking per safety and EMC
Download full specifications
Part number
Consumables
717-202-G1Compass,115V US adapter, English manual
717-202-G4Compass, 100V Japanese adapter, Japanese manual
717-202-G6Compass, 230V Euro adapter, English manual
703-020-G1Replacement Sensor
712-700-G1Spare Power Stick (batteries)
717-701-G1Replacement filters and probe cap
