INFICON ISO-KF fittings are manufactured according to ISO 2861/1, DIN 28403 and Pneurop 6606. Our quality fittings are the standard components for all vacuum and high vacuum applications. The high quality INFICON components are designed and tested for leak rates less than 1 x 10-9 mbar l/s.

Advantages

  • Competitively priced
  • World wide logistics
  • Design and measures follow strictly international respected standards
  • Surface finish, welds, material specifications and cleanliness meet or exceed high vacuum specifications
  • 2011/65/EU RoHS compliant

Specifications

 DN10 ISO-KFDN16 ISO-KFDN20 ISO-KF
Dimension A17 mm25 mm32 mm
Dimension B7 mm10 mm16 mm
Materialnatural rubber NR
Hardness45 ± 5 Shore A
Temperature-30 … +75 °C
For vacuum applications
Indicate length in meters
Download full specifications

Part Number

 Part NumberDescription
DN10 ISO-KF211-451Rubber vacuum hose, ø7/17
DN16 ISO-KF211-452Rubber vacuum hose, ø10/25
DN20 ISO-KF211-453Rubber vacuum hose, ø16/32
