The new Vortex® Dual combines the proven capabilities of previous Vortex instruments with new extended features to give you the fastest, smallest, and easiest to use refrigerant recovery machine yet.

Vortex Dual_A2L Certified
Vortex Dual_A2L Certified

Vortex® Dual sets itself apart by offering a full 1 HP dual piston compressor for the fastest recovery speeds available under real service conditions. A unique micro-channel condenser combined with an oversize fan helps lower discharge pressures resulting in sustained speed in the hottest ambient temperatures.


  • 1 HP dual piston compressor for industry leading recovery rates
  • Micro-channel condenser provides exceptional heat exchange allowing Vortex Dual to maintain recovery rates throughout the entire recovery cycle
  • Oversize fan provides exceptional cooling
  • Simple two valve operation
  • Full size protected gauges for both suction and tank pressure
  • Self-purge without the need to change hoses
  • Filter/dryer included
  • Noise absorbing blow molded case
  • Three-year over-the-counter replacement warranty


Unit IncludesShoulder strap, filter/dryer, 6 ft. (1.8 m) detachable power cord
Compatible refrigerantsRecovers commonly used CFCs, HCFCs, and HFCs including blends such as R410A, R12, R22, R134a, R32, R404, R407C, R500, R502, and other Class III, IV and V refrigerants
Weight29.75 lb. (13.5 kg)
Dimensions (L x W x H)16.7 x 9.2 x 14.2 in.
(42.4 x 23.3 x 36 cm)
Compressor1 HP oil-less, dual valve, AC motor drive
Download full specifications
Part Number
Spare Parts
714-202-G1Vortex Dual, 115V
714-202-G11Vortex Dual, 230V
068-0684Power Cord, 115V
