Refrigerant Leak Detector and Portable Monitor

D-TEK Stratus®

Find Profit-Crushing Leaks in No Time

D-Tek-Stratus

Product configurator

Gemini™ MxG5xx

Type
Sensor version
Ionization chamber
Emmision current
Flange connection to vacuum chamber
Switching function
Electrical connection
Digital interface
Analog output signal
Your configuration
inficon-gauge
Gemini™ MxG5xx
Flange
DN 16 ISO-KF
Switching functions
None
Electrical Connection
FCC, 8-pin
Digital Interface
None
Measurement range
1.2 - 8.68 V
Request
Personal information
Product
inficon-gauge
Gemini™ MxG5xx
Gemini™ MAG500
Your configuration has been successfully sent!

D-TEK Stratus combines the superior leak detection of INFICON D-TEK leak detectors with the cloud hunting capability of a portable monitor all in one hand-held unit. Quickly locate the area containing the leak using the large, easy-to-read LCD display, and then pinpoint the leak all with one instrument! D-TEK Stratus is the next big thing in refrigerant leak detection.

Always have the right sensor for the job

D-TEK Stratus is designed with versatility in mind. Quickly and easily switch to one of the optional sensors to look for refrigerant, CO2, or even flammable refrigerant leaks!

3In1SensorGraphic_EN
3In1SensorGraphic_EN

Features

  • Automatic and manual zero modes
  • Rugged carrying case included
  • Detects all CFCs, HCFCs, HFCs, and HFOs
  • Two year replacement warranty
  • Compatible with optional sensors for CO2 or flammable refrigerants

Advantages

  • Innovative cloud hunter mode with ppm readout helps locate leaks faster than ever
  • Cloud hunter and pinpoint modes is like having two leak detectors in one

All new, redesigned infrared sensor

  • Longest sensor life in the industry
  • Easy field replacement

New lithium ion battery

  • Quick charge capability
  • Easy field replacement

Designed for ergonomic comfort

Typical applications

  • Industrial AC & Refrigeration

Specifications

Includes

D-TEK Stratus

Infrared sensor

Lithium ion battery

Spare filters

AC wall charger

DC car charger

Extra-long probe

Carrying case

Earbuds

Compatible refrigerants
Refrigerant sensorRefrigerant
sensor

R22, R32, R134a, R404a, R407c, R410a, R422b, R448a, R449a, R452a, R452b, R507 (AZ50), R1234yf, ammonia, SF6, HFE and more



CO2 sensorCO2 sensor

R744 (CO2)



Flammable refrigerant sensorFlammable
refrigerant sensor

R290, R600a, R441a



Sensitivity per EN14624
R744 (CO2)R744 (CO2)2 g/a (0.07 oz./yr)1
R1234yfR1234yf0.5 g/a (0.02 oz./yr)
AmmoniaAmmonia3 g/a (0.1 oz./yr)
R290R2905 g/a (0.2 oz./yr)2
R134aR134a

1 g/a (0.04 oz./yr)



Power source

Lithium ion battery (rechargeable)

Micro USB (can operate while charging)

Certifications

CE

EN14624:2012

A2L Certified



1Requires 724-701-G2 CO2 Sensor
2Requires 724-701-G3 Flammable Refrigerant Sensor
Download full specifications
Part number
Accessories
Consumables
Spare Parts
724-202-G1D-TEK Stratus, North America
724-204-G1D-TEK Stratus (includes CO2 sensor only), North America
724-202-G11D-TEK Stratus, Europe
724-204-G11D-TEK Stratus (includes CO2 sensor only), Europe
724-202-CN41D-TEK Stratus, Asia
712-707-G1Filter cartridges, set of 5
721-605-G1Car Charger
721-606-G1Wall Charger
721-607-G1Earbuds
703-080-G10TEK-Check R134a Reference Leak
721-702-G1Battery
721-610-G1Charging Cradle
721-604-G1Battery/Charging Cradle Bundle
724-701-G1Refrigerant Sensor (Detects CFCs, HCFCs, HFCs, HFOs, and blends (including A2Ls))
724-701-G2CO2 Sensor
724-701-G3Flammable Refrigerant Sensor (Detects R290, R600a, and R441a)
724-701-G1Refrigerant Sensor (Detects CFCs, HCFCs, HFCs, HFOs, and blends (including A2Ls))
724-701-G2CO2 Sensor
712-707-G1Filter cartridges, set of 5
712-707-G1Filter cartridges, set of 5
724-705-G1D-TEK 3/Stratus Replacement Battery Door
721-605-G1Car Charger
721-606-G1Wall Charger
712-705-G1Replacement probe cap
724-703-G1Replacement probe
724-700-G1Carrying Case, D-TEK Stratus
