Elbow 90° DN 16 CF
213-301
Drop-in Options
Revolutionize your vacuum gauge experience with us!
INFICON CF quality fittings are manufactured according to ISO 3669 and the latest TS/ISO 3669-2 standard. INFICON Ultra high vacuum fittings are designed for applications down to 1 x 10-12 mbar and bakeout temperatures up to 400°C.
Advantages
- World wide logistics
- Design and measures follow strictly international respected standards
- Surface finish, welds, material specifications and cleanliness meet or exceed high vacuum specifications
- 2011/65/EU RoHS compliant
Specifications
| Dimension A | Dimension B | Dimension C | Dimension D | |
| DN16 ISO-CF | 38 mm | 0.5 mm | 0.5 mm | 15 mm |
| DN40 ISO-CF | 63 mm | 0.5 mm | 0.5 mm | 38 mm |
| DN63 ISO-CF | 105 mm | 1 mm | 1 mm | 66 mm |
| DN100 ISO-CF | 135 mm | 1 mm | 1 mm | 100 mm |
| DN160 ISO-CF | 167 mm | 1.5 mm | 1.5 mm | 150 mm |
Material: stainless steel 304L/1.4306
| ||||
Login to see prices, availability and purchased goods.
Order Information
Product
Elbow 90° DN 40 CF
213-302
Elbow 90° DN 63 CF
213-303
Elbow 90° DN 100 CF
213-304
Elbow 90° DN 160 CF
213-305
