ISO-KF
Schlauchadapter für Gummischlauch - Edelstahl

Product configurator
Gemini™ MxG5xx
Type
Sensor version
Ionization chamber
Emmision current
Flange connection to vacuum chamber
Switching function
Electrical connection
Digital interface
Analog output signal
Request
Your configuration has been successfully sent!
ISO-KF-Anschlüsse von INFICON werden gemäß ISO 2861/1, DIN 28403 und Pneurop 6606 gefertigt. Unsere hochwertigen Anschlüsse sind die Standardbauteile für alle Vakuum- und Hochvakuumanwendungen. Die hochwertigen INFICON-Komponenten sind für Leckraten unter 1 x 10-9 mbar l/s ausgelegt und getestet.
Vorteile
- Preisgünstig
- Weltweite Logistik
- Design und Maßnahmen richten sich strikt nach international anerkannten Standards
- Oberflächenfinish, Schweißstellen, Materialspezifikationen und Reinheit erfüllen oder übertreffen Spezifikationen für Hochvakuum
- 2011/65/EC RoHS-konform
Technische Daten
Typ | DN 16 ISO-KF | DN 25 ISO-KF | DN 40 ISO-KF |
Dimension A | 40 | 40 | 40 |
Dimension B | 7 | 7 | 7 |
Dimension C | 12 | 12 | 12 |
Material: | Stainless Steel 303 | Stainless steel 303 | Stainless Steel 303 |
C = | nominal connection for hose | nominal connection for hose | nominal connection for hose |
Artikelnummer
Artikelnummer | Beschreibung | |
DN 16 ISO-KF | 211-392 | Hose nipple, inox, DN 16 ISO-KF-12 |
DN 25 ISO-KF | 211-393 | Hose nipple, inox, DN 25 ISO-KF-12 |
DN 40 ISO-KF | 211-394 | Hose nipple, inox, DN 40 ISO-KF-12 |
