CF
PERNO EN T - ACERO INOXIDABLE 304L
Los conectores de calidad CF de INFICON se fabrican de acuerdo con la norma ISO 3669 y la norma TS/ ISO 3669-2 más reciente.

Product configurator
Gemini™ MxG5xx
Type
Sensor version
Ionization chamber
Emmision current
Flange connection to vacuum chamber
Switching function
Electrical connection
Digital interface
Analog output signal
Request
Your configuration has been successfully sent!
INFICON CF quality fittings are manufactured according to ISO 3669 and the latest TS/ ISO 3669-2 standard. INFICON Ultra high vacuum fittings are designed for applications down to 1 x 10-12 mbar and bakeout temperatures up to 400°C.
Ventajas
- Logística a escala mundial
- El diseño y las medidas siguen estrictamente los estándares internacionales
- El acabado de la superficie, las soldaduras y las especificaciones del material y la limpieza cumplen (o superan) los requisitos de alto vacío
- De conformidad con la normativa 2011/65/EU (RoHS)
Especificaciones
Type | Dimension A | Dimension B | Dimension C | Dimension D | Material: |
DN 16 CF | 38 | 0.5 | 0.5 | 15 | Stainless steel 304L / 1.4306 |
DN 40 CF | 63 | 0.5 | 0.5 | 38 | Stainless steel 304L / 1.4306 |
DN 63 CF | 105 | 1 | 1 | 66 | Stainless steel 304L / 1.4306 |
DN 100 CF | 135 | 1 | 1 | 100 | Stainless steel 304L / 1.4306 |
DN 160 CF | 167 | 1.5 | 1.5 | 150 | Stainless steel 304L / 1.4306 |
Número de parte
Part Number | Description | |
DN 100 CF | 213-314 | T piece DN 100 CF |
DN 16 CF | 213-311 | T-piece DN 16 CF |
DN 160 CF | 213-315 | T-piece DN 160 CF |
DN 40 CF | 213-312 | T-piece DN 40 CF |
DN 63 CF | 213-313 | T-piece DN 63 CF |
